LOW-E Glass coating production line

     Low-E glass adopt magnetron sputtering method to coat multi-layer metal, compound and medium film on the surface of high-quality float glass substrate. It can prevent radiation of heat from entering indoor and reflect heat of indoor, so that it can reduce the quantity of transmission radiation, possess advantage compare with other energy saving glass. This production line is composed by washing system, air pumping system, coating system, detection system and control system.

Products Conten

Main feature:

◆Adopts rotary twin target IF sputtering technology, increase the deposition efficiency of medium film and control the film thickness, uniformity and functionality are insured as well.

◆Adopts the PEM closed loop control system, make sure the coating is in the metal sputtering transmission zone, increase the deposition efficiency of medium film are insured as well.

◆Effective gas isolation is adopted in each sputtering area according to different target materials to ensure the stability of pressure, purity and stability of processing gas in each sputtering area.

◆Adopted imported PLC and control equipment, system communication through ControlNet network to realize the information exchange between the equipment, so that the whole system structure is simple and reliable.

◆Adopted on-line optical detection system, collect the substrate transmission, reflection spectrum data and curves etc. And compare with the standard data, to control the sputtering process effectively.



Production line model：

DXJLE-2436-28B-8      DXJLE-1824-28B-8

Workpiece size （mm)：

W2400×L3660               W1830×L2440

Note：

      Production line size and configuration can be customized according to customer requirements
